Designed For Filmmakers, Professionals And Industrial Applications
Variety Of Cameras + Gimbals Compatible For Use
A3 Pro Flight Controller And DJI Lightbridge 2 Integrated
Improved Design For Portability and Transportability
Extended Flight Time And Transmission Range
Professional HD Transmission And Powerful App Control
– Global International Shipping Available! Ask Us!
– Speak To A Product Professional Today! *Authorized DJI Dealer*

We Guarantee The Best Price And Will Beat Any Competitor’s Price. We can answer any questions via the Live Chat at the bottom right of your screen or by calling +1-855-UAV-4002 24 hours/day, 7 days/week

DJI MATRICE 600 PRO

The DJI Matrice 600 Pro (M600 Pro) is DJI’s new flying platform designed for professional aerial photography and industrial applications. Perfect for a variety of professionals, watch below for real-world applications!

Improvements: What’s Different?

The DJI Matrice 600 Pro (M600 Pro) inherits everything from the DJI Matrice 600 (M600) with improved flight performance and better loading capacity. Pre-installed arms and antennas reduce time required for setup, and the system’s modular design makes it easy to mount additional modules. The design makes portability and transportation more convenient.

The airframe is equipped with the latest DJI technologies, including the A3 Pro flight controller, Lightbridge 2 HD transmission system, Intelligent Batteries and Battery Management system. All Zenmuse cameras and gimbals are natively compatible and full integration with third party software and hardware make the M600 Pro ideal for professional aerial photography and industrial applications.

	Model	DJI Matrice 600 (M600)	DJI Matrice 600 Pro (M600 Pro)
AIRCRAFT	Weight (no-load operation with six TB47S batteries)	9.1Kg	9.5Kg
	Weight (no-load operation with six TB48S batteries)	9613g	9960g
	Max Take-off Weight	15.1kg	15.5kg
	Flight Controller	A3	A3 PRO
	Dampening system	无	Dampening balls at the bottom of IMU units and A3 main controller
	Max Flight Time (no-load operation with six TB47S batteries)	35mins	32mins
	Max Flight Time (no-load operation with six TB48S batteries)	40mins	38mins
	Flight Time (with load of 6Kg and six TB47S batteries)	16mins	16mins
	Flight Time (with load of 5.5Kg and six TB48S batteries)	18mins	18mins
	Propeller Model	DJI 2170	DJI 2170R
Transportation	Transportation Mode	Unpackaged	Packaged
Transportation	Transportation Dimensions (folded)	640582623mm（Without box）	520480640 mm（In box）
Charger	Model	Charging Hub（A14-100P1A）	M600 Pro charger with Charging Hub（MC6S600）
	Voltage	26.1V	26.1V
	Rated Power	100W	600W

Video: In Action

Here's a video of the DJI Agras MG-1P Crop Sprayer in action.

Features

A3 Pro Flight Controller
Complete Integration Ultra Convenient
Charge 6 Batteries Simultaneously
Complete Aerial Imaging Solution
Compatible With A Variety Of Cameras
Extended Flight Time and Transmission Range
Professional HD Transmission: DJI Lightbridge 2
Integrated D-RTK GNSS
Open SDK Development
Powerful App Control: DJI Go + DJI Assistant 2
Flight time and performance based on payload 18 -40 minutes
Professionally reliable performance with a maximum payload of 6KG
Operating range of 5KM with real time UHD video footage
DJI Matrice 600 Pro fully compatible for software developers or industrial applications

Increased water resistance with sealing films added to ESC
Intelligent Flight Modes: Smart Mode/Manual Plus/Manual Mode
Real-Time Safety Features empty tank warning, operation resumption, system data protection
Nozzles now have flow sensors for added data and efficiency
Terrain Follow scans the terrain below in real-time, adjusts constantly to maintain height above crops
Dedicated Remote Controller
New optional battery charging hub charges 12 batteries in sequence
Ready To Fly: everything you need to fly included, pre-tested by our experienced technicians

A3 Pro Flight Controller

A3 Pro Flight Controller

The A3 Pro Flight Controller has triple modular redundancy and diagnostic algorithms that compare sensor data from three sets of GNSS units, with additional analytical redundancies for a total of six. A new dampensing system for the A3’s modules enable precise control of multi-rotor aircraft, providing accurate data for stable flight performance. Self-adaptive systems will automatically adjust flight parameters based on different payload. Compatibility with D-RTK GNSS means that the A3 Pro can withstand magnetic interference, providing centimeter-level accuracy, suitable for various industrial applications.

Complete Integration Ultra Convenient

Complete Integration Ultra Convenient

The DJI Matrice 600 Pro is simple and easy to set-up, ready to fly in a matter of minutes. Its airframe has been optimized for easier transportation with a quick-release landing gear design and folding frame arms.

Under the new upper cover, the positions of GNSS modules and sensors have been revamped and a new dampening system for the IMU units increases reliability during flight. The M600 Pro also comes with a durable, customizable case that absorbs impact from shakes or falls, providing all-round protection when carried or transported.

Charge Six Batteries Simultaneously

Charge Six Batteries Simultaneously

The DJI Matrice 600 Pro Charger has six charging hubs, enabling it to charge six Intelligent Batteries simultaneously. All six batteries can be fully charged in a short amount, for quick and efficient preparation.

Batteries can be charged in 92 minutes for TB47S, and 110 minutes for TB48S.

Aerial Imaging Solution

Aerial Imaging Solution

Dustproof propulsion systems simplify maintenance and active cooling motors ensure that operation is reliable for extended periods of time. The DJI Matrice 600 Pro is natively compatible with current Zenmuse cameras and gimbals. With a maximum payload of 6kg, it effortlessly supports the Ronin-MX gimbal, DJI Focus and a range of cameras from Micro Four Thirds systems to the RED EPIC.

Extended Flight Time and Transmission Range

Extended Flight Time and Transmission Range

The DJI Matrice 600 Pro has an extended flight time and a 5km long-range transmission. A comprehensive battery management system means that if any of its six Intelligent Batteries are turned on or off, the rest will follow suit. The battery management system monitors every battery during flight, ensuring safe landing in the event of single battery failure. Compared to traditional non-intelligent batteries, the DJI Matrice Pro battery management system simplifies maintenance while enhancing security.

Mission Planner Software

Professional HD Transmission

DJI Lightbridge 2 has been designed to meet all the requirements of professional broadcasting, offering high frame rates and HD live streaming. USB, mini-HDMI, 3G-SDI ports and Lightbridge 2 Ground Unit all support video output at up to 1080p/60fps. Dynamic, self-adaptive wireless data links enable long-range transmission with ultra-low latency, supporting a broadcast standard output of 720p/59.94fps and 1080i/50fps, enabling even more creative opportunities for aerial imaging.

D-RTK GNSS

D-RTK GNSS

Using dual antennas, the D-RTK GNSS system is a significant breakthrough for high-precision industrial applications. It is able to withstand strong magnetic interference and provides centimeter-level accuracy in environments with metal structures.

Open SDK Development

Open SDK Development

The M600 Pro is fully compatible with the DJI Onboard SDK and Mobile SDK to meet the requirements of those building software for various industrial applications. It has four — dual parallel — CAN ports and one API port for connecting DJI devices, including the D-RTK GNSS units or third party components of your choice.

Powerful App Control

Powerful App Control

The DJI Matrice 600 Pro supports the DJI GO app and DJI Assistant 2. Get a live HD view, battery status, redundancy status, transmission strength and much more, straight from the DJI GO app.

DJI GO is also the control center for the camera, giving access to shutter speed, ISO, photo or video capture, on any Zenmuse series camera and remote focus and aperture control on the Zenmuse X5 and X5R cameras. DJI Assistant 2 supports firmware updates and Ground Station, and comes with a built-in flight simulator.

American Flag

Made In USA Components

We are proud to have ditched the Chinese components, and swapped them for higher quality made in USA parts were possible. Now, the Pixhawk flight controller, GPS system, telemetry, ultrasonic sonar, and electronic speed controller are all manufactured in the USA. The only main parts that are manufactured in China are the carbon fiber frame, motors, and controller. Upon request, we also have alternative options available to replace those parts.

Continuous Improvement Program

Every single week, our engineers make upgrades to the Tarot 650 V2.1 based on their testing and customer feedback. Our continuous improvement program is so good that you might wonder when can ever be the right time to buy if there will be a better version next week. As a result, we have begun offering the continuous improvement program, included with all Tarot 650’s purchased from January 2019 onwards. You can send your Tarot 650 back to us at any time in the future and for $299.99, we will upgrade it with the latest and greatest improvements we have introduced since you purchased it.

Purchase With Confidence

PO Terms

We can accept Net 30 purchase orders from most customers, with a few exceptions. Our team will determine eligibility on a case by case basis. Only pay for the drone when you have received it and are satisfied.

30 Day Money Back Guarantee

We know you will love our products, but in the case you are not happy with the drone for any reason within the first 30 days, return it to us for a full refund.

EDU/GOV Discounts

Are you a school, university, government agency or contractor? You may qualify for discounts depending on what you purchase.

Ask one of our sales agents through chat or e-mail, which would love to inform you about the possibilities for you.

8.8/10

Join Our Customers In 100+ Countries

Specifications

Diagonal Wheelbase :- 1133 mm
Dimensions :- 1668 mm × 1518 mm × 727 mm with propellers, frame arms and GPS mount unfolded (including landing gear)
437 mm × 402 mm × 553 mm with propellers, frame arms and GPS mount folded (excluding landing gear)
Package Dimensions :- 525 mm × 480 mm × 625 mm
Weight (with six TB47S batteries) :- 9.5 kg
Weight (with six TB48S batteries) :- 10 kg
Max Takeoff Weight Recommended :- 15.5 kg
Hovering Accuracy (P-GPS) :- Vertical: ±0.5 m, Horizontal: ±1.5 m
Max Angular Velocity :- Pitch: 300°/s, Yaw: 150°/s
Max Pitch Angle :- 25°
Max Wind Resistance :- 8 m/s
Max Ascent Speed :- 5 m/s
Max Descent Speed :- 3 m/s
Max Speed :- 40 mph / 65 kph (no wind)
Max Service Ceiling Above Sea Level :- 2500 m
Hovering Time* (with six TB47S batteries) :- No payload: 32 min, 6 kg payload: 16 min
Hovering Time* (with six TB48S batteries) :- No payload: 38 min, 5.5 kg payload: 18 min
Flight Control System :- A3 Pro
Supported DJI Gimbals :- Ronin-MX; ZENMUSETM Z30, Zenmuse X5/X5R, Zenmuse X3, Zenmuse XT; Zenmuse Z15 Series HD Gimbal: Z15-A7, Z15-BMPCC, Z15-5D III, Z15-GH4
Retractable Landing Gear :- Standard
Operating Temperature :- 14° to 104° F (-10° to 40° C)

What’s Included?

Aircraft Body
Landing Gear Leg
Landing Skid
Spring
Remote Controller
Intelligent Battery
Hex Battery Charger
Inner Foam Case
Power Cable
RC Charging Cable
Micro USB Cable
Knob (with Gasket)
Tape
Battery Stickers
Screws
Manuals
D-RTK High Precision Positioning System
Zenmuse Z30 Mounting Kit
Zenmuse X Series Mounting Kit
Z15 Series HD Gimbal Brackets
Intelligent Flight Battery
Power Hub
Upper Expansion Bay
2195 Foldable Propeller

User Manual

Want to check out the Matrice 600 Pro to get a full understanding of our Matrice 600 Pro before you place an order, or lost the manual that was included with your drone? Click here to download a PDF version of our user manual?

Parts And Accessories

Speak with our experienced product professionals via the chat function at the bottom of the screen if you would like to add any accessories such as additional batteries, propellers, or anything else to your order. We have a wide range of compatible parts that can improve your flight experience!

Charger (Model: MC6S600)

Voltage Output :- 26.1 V
Rated Power :- 600 W
Single Battery Port Output Power :- 100 W

Optional Battery (Model: TB48S)

Capacity :- 5700 mAh
Voltage :- 22.8 V
Battery Type :- LiPo 6S
Energy :- 129.96 Wh
Net Weight :- 680 g
Operating Temperature :- 14° to 104° F (-10° to 40° C)
Max Charging Power :- 180 W

Remote Controller

Operating Frequency :- 920.6 MHz to 928 MHz (Japan); 5.725 GHz to 5.825 GHz; 2.400 GHz to 2.483 GHz
Max Transmission Distance :- FCC Compliant: 3.1 mi (5 km), CE Compliant: 2.2 mi (3.5 km) (Unobstructed, free of interference)
Transmitter Power (EIRP) :- 10 dBm @ 900M, 13 dBm @ 5.8G, 20 dBm @ 2.4G
Video Output Port :- HDMI, SDI, USB
Operating Temperature :- 14° to 104° F (-10° to 40° C)
Battery :- 6000 mAh LiPo 2S

Standard Battery (Model: TB47S)

Capacity :- 4500 mAh
Voltage :- 22.2 V
Battery Type< :- LiPo 6S
Energy :- 99.9 Wh
Net Weight :- 595 g
Operating Temperature :- 14° to 104° F (-10° to 40° C)
Max Charging Power :- 180 W

Features

Total Weight (without batteries) :- 8.8 kg
Standard Takeoff Weight :- 22.5 kg
Max Takeoff Weight :- 24.5 kg (@ sea level)
Max Thrust-Weight Ratio :- 1.81 (with 22.5 kg takeoff weight)
Power Battery :- DJI Designated Battery (MG-12000)
Max Power Consumption :- 6400 W
Hovering Power Consumption :- 3250 W (with 22.5 kg takeoff weight)
Hovering Time :- 24 min (@ with 12.5 kg takeoff weight)
Max Operating Speed :- 10 min (@ with 22.5 kg takeoff weight)
Max Flying Speed :- 8 m/s , 22 m/s
Recommended Operating Temperature :- 0 to 40℃

Remote Controller

Model :- GL690B（Japan Only）, GL658C
Operating Frequency :- 2.400 - 2.483 GHz
Max Transmission Range (unobstructed, free of interference) :- 1km
EIRP
100 mW @ 2.4 GHz
Built-in Battery :- 6000 mAh, 2S LiPo
Charging :- DJI charger
Output Power :- 9 W
Operating Temperature Range :- 10 to 40℃
Storage Temperature Range :- Less than 3 months: -20 to 45℃
More than 3 months: 22 to 28℃
Charge Temperature Range :- 0 to 40℃
